Specifications:

OpenVox Unified Communication Platform (UCP) is the ideal solution to integrate data, voice and video in one product for small and medium-sized enterprises, which can be used in scenarios such as government and enterprise call systems, commercial call centers, and dispatch center industries.

The UCP product series include the chassis, switchboard, main control board and module boards, etc. The concept of UCP is that users can choose different functional and performance module boards and control boards according to their needs, and these modules are connected to the backplane via high-speed Ethernet through special communication connectors. UCP products adopt SIP softswitch core, high integration, broadband and narrowband integrated design, which can effectively improve communication efficiency and reduce operating costs.



Features:

• Modular design allows users to directly install, configure or remove communication modules such as switch boards, main control boards and service boards. Switching and service modules can support hot-swapping.
• Each module is connected by high-speed Ethernet, and then connected to PSTN (Public Switched Telephone Network) or private network voice switching equipment through wireless trunking, digital trunking, analog trunking, and broadband SIP trunking.
• The main control module is compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers, and can be installed with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms, etc.
• The service module is connected to the master via SIP signaling; in terms of software docking, it is perfectly compatible with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms.



Technical Specifications:

Chassis	UCP1600	UCP2120	UCP4131
Slot	1 main control board slot 4 module board slots	2 main control board slot 9 module board slots	2 main control board slot 9 module board slots 2 power supply slots
Weight	3.9kg	5.6kg	9.6kg
Dimension	44mm*434mm*330mm (height*width*length)	88mm*434mm*330mm (height*width*length)	176.3mm*435.8mm*330mm (height*width*length)
Redundant Power Supply	NO	Yes
DC Powe Supply	NO	Yes
Maximum Power	64W	170W	340W
Maximum Output Power (AC power)	75W	200W	400W
Input Voltage（AC power）	100V~240V AC
Input Voltage（DC power）	NO	-48V ~ -60V DC
Power Frequency（AC power）	50Hz/60Hz
Long-term Working Temperature	0°C ~ 45°C
Short-term Working Temperature	- 5°C ~ 55°C
Ambient Humidity	5% ~ 95%, non-condensing
Storage Temperatue	-40°C ~ 70°C



Features:

OpenVox Unified Communication Platform (UCP) is not just a VoIP gateway or an IPPBX, it is a hybrid unified communication platform that includes both VoIP gateway and IPPBX functions. You can simply customize your IPPBX and VoIP gateway with different interface modules in one chassis. UCP supports Core Switch Unit (CSU), Core Control Unit(CCU), and Module Unit. The Module Unit includes Wireless Trunk Unit (WTU), Analog Interface Unit (AIU), Digital Trunk Unit (DTU), RIU (Radio Interface Unit), ACU (Audio Communication Unit), RAID Storage Unit (RSU) and Storage Expand Unit (SEU), supporting access to GSM/LTE lines, analog lines, digital lines, RAID and storage expansion. The UCP service boards can be optional depending on the system's capacity. Empty slots for unconfigured interface boards, need to install empty panels.

The UCP1600 is a 1U standard chassis, 434mm wide, 330mm deep and 44mm high, which can be installed in a 19-inch cabinet by IEC (International Electrotechnical Commission) standards. The UCP1600 provides one main control board slot and four module board slots to meet the business needs of users under 100. The main control board module is X86 architecture and works as an individual IPPBX system with Linux and Windows support. In addition, the service board will identify the initial IP address based on the slot number, e.g. slot 2: 172.16.80.2.



Service Board Specifications:

UCP1600 Service Board Option
CSU (Core Switch Unit)	CSU-F	100M Switch; Support 100M ETH port*2, Console*1, RST*1;
	CSU-G	1000M Switch; Support 1000M ETH port*3, SFP*1, RST*1;
CCU (Core Control Unit)	CCU-N-BAYL	Intel Bay Trail quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*1, RST*1;
	CCU-N-GML	Intel Celeron Gemini Laky quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*1, RST*1;
Module Unit	WTU (Wireless Trunk Unit)	Support 4 GSM/LTE channels access;
	AIU-8 (Analog Interface Unit-8)	Support 8 FXO, 8 FXS, 4 FXO and 4FXS interfaces;
	AIU-16 (Analog Interface Unit-16)	Support 16 FXS interfaces;
	MIU (Magnet Interface Unit)	Support 4/8 magnet ports;
	DTU (Digital Trunk Unit)	Support 1/2/4 E1/T1 access;
	RIU (Radio Interface Unit)	Support 2/4 radio trunk ports;
	ACU (Audio Communication Unit)	Support 2 pairs audio ports;
	SEU (Storage Expand Unit)	Supports 2.5-inch mechanical or SSD; (Needs to be used with CCU)





Download:

PDF Manual

• UCP1600 Datasheet
• UCP Series Product Manual
• What is UCP

Online Manual

• UCP Series Product Manual

Accessories:

CCU Main Control Module and Accessories

CCU-N-GML (VS-CCU-GML)

Intel Celeron Gemini Laky quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*1, RST*1;

CCU-N-BAYL (VS-CCU-N2930AM)

Intel Bay Trail quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*1, RST*1;

SEU (Storage Expand Unit)

Supports 2.5-inch mechanical or SSD;



Module Unit

WTU-GSM (VS-GWM401G)

Support 4 channel GSM access;

WTU (VS-GWM401L)

Support 4 channel LTE access;

AIU-8 (VS-GWM801)

Support 8 FXO, 8 FXS, 4 FXO and 4 FXS interfaces;

AIU-16 (FXS16)

Support 16 FXS interfaces;

DTU-301

Support 1 E1/T1 cost-effective access;

DTU (VS-ET200X)

Support 1/2/4 E1/T1 access;

MIU (Magnet Interface Unit)

Support 4/8 magnet ports;

RIU (Radio Interface Unit)

Support 2/4 radio trunk ports;

ACU (Audio Communication Unit)

Support 2 pairs audio ports;

Use standard SIP protocol;

Provide 1 main control board slot and 4 module board slots;

Compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers;

Support most VoIP operating system platforms, such as Asterisk, Elastix, 3CX, FreeSWITCH, Broadsoft and so on.

Specifications:

OpenVox Unified Communication Platform (UCP) is the ideal solution to integrate data, voice and video in one product for small and medium-sized enterprises, which can be used in scenarios such as government and enterprise call systems, commercial call centers, and dispatch center industries.

The UCP product series include the chassis, switchboard, main control board and module boards, etc. The concept of UCP is that users can choose different functional and performance module boards and control boards according to their needs, and these modules are connected to the backplane via high-speed Ethernet through special communication connectors. UCP products adopt SIP softswitch core, high integration, broadband and narrowband integrated design, which can effectively improve communication efficiency and reduce operating costs.



Features:

• Modular design allows users to directly install, configure or remove communication modules such as switch boards, main control boards and service boards. Switching and service modules can support hot-swapping.
• Each module is connected by high-speed Ethernet, and then connected to PSTN (Public Switched Telephone Network) or private network voice switching equipment through wireless trunking, digital trunking, analog trunking, and broadband SIP trunking.
• The main control module is compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers, and can be installed with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms, etc.
• The service module is connected to the master via SIP signaling; in terms of software docking, it is perfectly compatible with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms.



Technical Specifications:

Chassis	UCP1600	UCP2120	UCP4131
Slot	1 main control board slot 4 module board slots	2 main control board slot 9 module board slots	2 main control board slot 9 module board slots 2 power supply slots
Weight	3.9kg	5.6kg	9.6kg
Dimension	44mm*434mm*330mm (height*width*length)	88mm*434mm*330mm (height*width*length)	176.3mm*435.8mm*330mm (height*width*length)
Redundant Power Supply	NO	Yes
DC Powe Supply	NO	Yes
Maximum Power	64W	170W	340W
Maximum Output Power (AC power)	75W	200W	400W
Input Voltage（AC power）	100V~240V AC
Input Voltage（DC power）	NO	-48V ~ -60V DC
Power Frequency（AC power）	50Hz/60Hz
Long-term Working Temperature	0°C ~ 45°C
Short-term Working Temperature	- 5°C ~ 55°C
Ambient Humidity	5% ~ 95%, non-condensing
Storage Temperatue	-40°C ~ 70°C



Features:

OpenVox Unified Communication Platform (UCP) is not just a VoIP gateway or an IPPBX, it is a hybrid unified communication platform that includes both VoIP gateway and IPPBX functions. You can simply customize your IPPBX and VoIP gateway with different interface modules in one chassis. UCP supports Core Switch Unit (CSU), Core Control Unit(CCU), and Module Unit. The Module Unit includes Wireless Trunk Unit (WTU), Analog Interface Unit (AIU), Digital Trunk Unit (DTU), RAID Storage Unit (RSU) and Storage Expand Unit (SEU), supporting access to GSM/LTE lines, analog lines, digital lines, RAID and storage expansion. The UCP service boards can be optional depending on the system's capacity. Empty slots for unconfigured interface boards, need to install empty panels.

The UCP4131 is a 4U standard chassis, 435.8mm wide, 330mm deep and 176.3mm high, which can be installed in a 19-inch cabinet by IEC (International Electrotechnical Commission) standards. The UCP4131 provides 2 main control board slots, 9 module board slots and 2 power supply slots to meet the business needs of users from 1000 to 10000. The main control board module is X86 architecture and works as an individual IPPBX system with Linux and Windows support. In addition, the service board will identify the initial IP address based on the slot number, e.g. slot 2: 172.16.80.2.



Service Board Specifications:

UCP4131 Service Board Option
CSU (Core Switch Unit)	CSU-F	100M Switch; Support 100M ETH port*2, Console*1, RST*1;
	CSU-G	1000M Switch; Support 1000M ETH port*3, SFP*1, RST*1;
CCU (Core Control Unit)	CCU-N-GML	Intel Celeron Gemini Laky quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*1, RST*1;
	CCU-I-TGL	Intel 11th Generation i5/i7 quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*2, RST*1;
Module Unit	WTU (Wireless Trunk Unit)	Support 4 GSM/LTE channels access;
	AIU-8 (Analog Interface Unit-8)	Support 8 FXO, 8 FXS, 4 FXO and 4FXS interfaces;
	AIU-16 (Analog Interface Unit-16)	Support 16 FXS interfaces;
	MIU (Magnet Interface Unit)	Support 4/8 magnet ports;
	DTU (Digital Trunk Unit)	Support 1/2/4 E1/T1 access;
	RIU (Radio Interface Unit)	Support 2/4 radio trunk ports;
	ACU (Audio Communication Unit)	Support 2 pairs audio ports;
	SEU (Storage Expand Unit)	Supports 2.5-inch mechanical or SSD; (Needs to be used with CCU)











Download:

PDF Manual

• UCP4131 Datasheet
• UCP Series Product Manual
• What is UCP

Online Manual

• UCP Series Product Manual

Accessories:

CCU Main Control Module and Accessories

CCU-I-KABYLR (VS-CCU-I5)

Intel Kaby Lake R quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*2, RST*1;

CCU-I-TGL

11th Generation Intel(R) Core(R) i5 Processors;
Support 1000M ETH port*3, HDMI*1, USB*2, RST*1;

SEU (Storage Expand Unit)

Supports 2.5-inch mechanical or SSD;



Module Unit

WTU-GSM (VS-GWM401G)

Support 4 channel GSM access;

WTU (VS-GWM401L)

Support 4 channel LTE access;

AIU-8 (VS-GWM801)

Support 8 FXO, 8 FXS, 4 FXO and 4 FXS interfaces;

AIU-16 (FXS16)

Support 16 FXS interfaces;

DTU-301

Support 1 E1/T1 cost-effective access;

DTU (VS-ET200X)

Support 1/2/4 E1/T1 access;

RSU (RAID Storage Unit)

Support RAID 0 and RAID 1;

MIU (Magnet Interface Unit)

Support 4/8 magnet ports;

RIU (Radio Interface Unit)

Support 2/4 radio trunk ports;

ACU (Audio Communication Unit)

Support 2 pairs audio ports;

Use standard SIP protocol;

Provide 2 main control board slots, 9 module board slots and 2 power supply slots;

Compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers;

Support most VoIP operating system platforms, such as Asterisk, Elastix, 3CX, FreeSWITCH, Broadsoft and so on.

Specifications:

OpenVox Unified Communication Platform (UCP) is the ideal solution to integrate data, voice and video in one product for small and medium-sized enterprises, which can be used in scenarios such as government and enterprise call systems, commercial call centers, and dispatch center industries.

The UCP product series include the chassis, switchboard, main control board and module boards, etc. The concept of UCP is that users can choose different functional and performance module boards and control boards according to their needs, and these modules are connected to the backplane via high-speed Ethernet through special communication connectors. UCP products adopt SIP softswitch core, high integration, broadband and narrowband integrated design, which can effectively improve communication efficiency and reduce operating costs.



Features:

• Modular design allows users to directly install, configure or remove communication modules such as switch boards, main control boards and service boards. Switching and service modules can support hot-swapping.
• Each module is connected by high-speed Ethernet, and then connected to PSTN (Public Switched Telephone Network) or private network voice switching equipment through wireless trunking, digital trunking, analog trunking, and broadband SIP trunking.
• The main control module is compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers, and can be installed with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms, etc.
• The service module is connected to the master via SIP signaling; in terms of software docking, it is perfectly compatible with Asterisk, Elastix, trixbox, 3CX and other SIP servers or VOS VoIP operation platforms.



Technical Specifications:

Chassis	UCP1600	UCP2120	UCP4131
Slot	1 main control board slot 4 module board slots	2 main control board slot 9 module board slots	2 main control board slot 9 module board slots 2 power supply slots
Weight	3.9kg	5.6kg	9.6kg
Dimension	44mm*434mm*330mm (height*width*length)	88mm*434mm*330mm (height*width*length)	176.3mm*435.8mm*330mm (height*width*length)
Redundant Power Supply	NO	Yes
DC Powe Supply	NO	Yes
Maximum Power	64W	170W	340W
Maximum Output Power (AC power)	75W	200W	400W
Input Voltage（AC power）	100V~240V AC
Input Voltage（DC power）	NO	-48V ~ -60V DC
Power Frequency（AC power）	50Hz/60Hz
Long-term Working Temperature	0°C ~ 45°C
Short-term Working Temperature	- 5°C ~ 55°C
Ambient Humidity	5% ~ 95%, non-condensing
Storage Temperatue	-40°C ~ 70°C



Features:

OpenVox Unified Communication Platform (UCP) is not just a VoIP gateway or an IPPBX, it is a hybrid unified communication platform that includes both VoIP gateway and IPPBX functions. You can simply customize your IPPBX and VoIP gateway with different interface modules in one chassis. UCP supports Core Switch Unit (CSU), Core Control Unit(CCU), and Module Unit. The Module Unit includes Wireless Trunk Unit (WTU),  Analog Interface Unit (AIU), Digital Trunk Unit (DTU), RAID Storage Unit (RSU) and Storage Expand Unit (SEU), supporting access to GSM/LTE lines, analog lines, digital lines, RAID and storage expansion. The UCP service boards can be optional depending on the system's capacity. Empty slots for unconfigured interface boards, need to install empty panels.

The UCP2120 is a 2U standard chassis, 434mm wide, 330mm deep and 88mm high, which can be installed in a 19-inch cabinet by IEC (International Electrotechnical Commission) standards. The UCP2120 provides 2 main control board slots and 9 module board slots to meet the business needs of users from 100 to 1000. The main control board module is X86 architecture and works as an individual IPPBX system with Linux and Windows support. In addition, the service board will identify the initial IP address based on the slot number, e.g. slot 2: 172.16.80.2.



Service Board Specifications:

UCP2120 Service Board Option
CSU (Core Switch Unit)	CSU-F	100M Switch; Support 100M ETH port*2, Console*1, RST*1;
	CSU-G	1000M Switch; Support 1000M ETH port*3, SFP*1, RST*1;
CCU (Core Control Unit)	CCU-N-BAYL	Intel Bay Trail quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*1, RST*1;
	CCU-N-GML	Intel Celeron Gemini Laky quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*1, RST*1;
	CCU-I-TGL	Intel 11th Generation i5/i7 quad-core processor; Support 1000M ETH port*3, HDMI*1, USB*2, RST*1;
Module Unit	WTU (Wireless Trunk Unit)	Support 4 GSM/LTE channels access;
	AIU-8 (Analog Interface Unit-8)	Support 8 FXO, 8 FXS, 4 FXO and 4FXS interfaces;
	AIU-16 (Analog Interface Unit-16)	Support 16 FXS interfaces;
	MIU (Magnet Interface Unit)	Support 4/8 magnet ports;
	DTU (Digital Trunk Unit)	Support 1/2/4 E1/T1 access;
	RIU (Radio Interface Unit)	Support 2/4 radio trunk ports;
	ACU (Audio Communication Unit)	Support 2 pairs audio ports;
	SEU (Storage Expand Unit)	Supports 2.5-inch mechanical or SSD; (Needs to be used with CCU)





Download:

PDF Manual

• UCP2120 Datasheet
• UCP Series Product Manual
• What is UCP

Online Manual

• UCP Series Product Manual

Accessories:

CCU Main Control Module and Accessories

CCU-N-GML (VS-CCU-GML)

Intel Celeron Gemini Laky quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*1, RST*1;

CCU-N-BAYL (VS-CCU-N2930AM)

Intel Bay Trail quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*1, RST*1;

CCU-I-KABYLR (VS-CCU-I5)

Intel Kaby Lake R quad-core processor;
Support 1000M ETH port*2, HDMI*1, USB*2, RST*1;

CCU-I-TGL

11th Generation Intel(R) Core(R) i5 Processors;
Support 1000M ETH port*3, HDMI*1, USB*2, RST*1;

SEU (Storage Expand Unit)

Supports 2.5-inch mechanical or SSD;



Module Unit

WTU-GSM (VS-GWM401G)

Support 4 channel GSM access;

WTU-LTE (VS-GWM401L)

Support 4 channel LTE access;

AIU-8 (VS-GWM801)

Support 8 FXO, 8 FXS, 4 FXO and 4 FXS interfaces;

AIU-16 (FXS16)

Support 16 FXS interfaces;

DTU-301

Support 1 E1/T1 cost-effective access;

DTU (VS-ET200X)

Support 1/2/4 E1/T1 access;

MIU (Magnet Interface Unit)

Support 4/8 magnet ports;

RIU (Radio Interface Unit)

Support 2/4 radio trunk ports;

ACU (Audio Communication Unit)

Support 2 pairs audio ports;

Use standard SIP protocol;

Provide 2 main control board slots and 9 module board slots;

Compatible with mainstream IMS/NGN platforms, IPPBX and SIP servers;

Support most VoIP operating system platforms, such as Asterisk, Elastix, 3CX, FreeSWITCH, Broadsoft and so on.

Specifications:

CCU-N-BAYL is a new main control board developed for VoIP applications. With intel Quad Core processors, CCU-N-BAYL can handle up to 600 concurrent G.711 calls and 1000 users. To bring you clear, high fidelity and high definition audio/video calls, CCU-N-BAYL can easily integrate with abundant HD voice and video codecs.

The CCU-N-BAYL supports comprehensive protocol processing, including SIP, IAX2 protocols in IP side and BRI, PRI, SS7, R2, GSM, WCDMA in CPE side. Taking the full advantages of open source platform,the CCU-N-BAYL will be preloaded with OpenVox UC PBX System, PBX in a FlashTM, FreePBX IPPBX software.

Technical Specifications

• Freely install your own Linux-based software
• CPU: Intel(R) Celeron(R) J1900 or N2930
• RAM: Up to 8GB DDR3L 1333
• Storage: MSATA SSD onboard and 2.5 inch SATA HDD
• NIC: 3 Gigabit Ethernet (two on the front panel and one on the back panel)
• Power Supply: 100-240V AC
• Display: 1 Type A HDMI port
• USB: 1
• Power Consumption: ~7.5W (Minimum Power Dissipation)
• Operating Temperature: 0°C to 50 °C
• Storage Temperature: -40 °C ~ 125 °C
• Humidity: 10 ~ 90% NON-CONDENSING

Certifications

• RoHS Complaint

Software & Platform:

• Issabel，Elastix，FreePBX，VitalPBX，BrikerPBX

Features:

PBX

• Users: Unlimited
• Max VoIP Trunks: Unlimited
• Max Concurrent Calls: 600 Concurrent Calls with G.711 Codec, 200 Concurrent Calls with G.729 Codec
• Transport Protocol: UDP, TCP, TLS, SRTP
• DTMF: In-band, RFC2833, SIP INFO
• IP Services: Static IP, DHCP, VPN, Firewall, PPPoE, Bridge
• Supported codecs: ADPCM, G.711(A-Law & u-Law), G.722, G.723.1(pass through), G.726, G.728, G.729, GSM, iLBC(optional) among others.
• SIP and IAX2 support
• Web-based operator panel
• DISA(Direct Inward System Access)
• Call detail record(CDR) report
• Call recording, Call parking, call queues, Voicemail, Conference
• Echo canceller
• Callback support
• Flexible and configuration IVR
• Support for PIN sets
• Support for time conditions
• VOIP provider configuration
• Support for follow-me
• Support for ring groups
• Support for video-phones
• Channel usage reports

Warranty

• One-Year Warranty
• 3-Month "No-Question Asked Return Policy"

Preloaded System

• OpenVox UC PBX System
• 3CX V16 based on debian 10
• Issabel 4.0
• FreePBX
• CentOS 7.8
• Debian 9.8

Accessories:

VS-CCU-500HDD

2.5 inches 500G HDD



Intel Celeron J1900 or N2930;

MSATA SSD / 2.5 inch HDD;

One-Year warranty;

1 USB port; 3 Gigabit Ethernet ports; 1 HDMI port;

Up to 600 concurrent calls and 1000 users;

A main control board developed for VoIP applications.
